Metering units

Cabinet	A separate meter cabinet is placed at the rear end with a single uplift door with jacks and rubber door seals
Flow meter	Imported from USA Positive displacement, Tri – Rotor/PISTON Strainer cum Mechanical Counter (5 digits resettable batch & 8 digits Non-re settable Totalizer) Pumping capacity up to 200LPM calibrated to 60 – 70 LPM.
Accuracy	Measuring accuracy +/- 0.1 to 0.3 %
Approval	Approved by weights and measure in India PESO Approved (PETROLEUM AND EXPLOSIVES)
Air eliminator	Eliminating air particles in the fuel line.
Pre setter	Choosing the quantity of the fuel you need to dispense.
Hose reel	1” self rewinding type
Delivery nozzle	1” auto cut off opw nozzle
Pump	Pto driven Peso approved

Testing

Tank	Leak test, pressure test, compartment internal passing test, etc
Metering Unit	Accuracy calibration test, pressure test, etc
Pump	Flow rate testing, pressure relief test, by passing test.
Hose	Reel retraction
Delivery	Pressure vent in the manhole, fire safety emergency valve, fire extinguishers.
Static Current	Static earth reel with retraction.
Rust	Rustproofing
Safety	Pressure vent in the manhole, fire safety emergency valve, fire extinguishers.

Tank

Capacity	2 compartments (2kl + 2kl = total capacity 4kl) (1kl =1000litres)
Shell	Tank shell is made out of ms plate
Dish	Dish is made out of ms plate. It is profiled type dish which can hold the liquids and reduce the waves and damping pressure.
Mounting legs	Tank leg is pre-fabricated with 4mm ms plate forms a load bearing and load distribution chassis type with u clamp pockets and cradle support box on both the sides
Control valves	Two ball valves which operate independently for each compartment and a common valve which can be used to take out the product directly from the tank gravity flow.
Safety fittings	PV valve, emergency valve, emergency vent, fill pipe dip rod assembled on a manhole individually in each compartment. One fire extinguisher.
Strainer	Additional strainer is added in the circuit to filter the foreign particles in the diesel.
Manhole	Manhole bowl, ladder, rail, mudguard, bumper, etc.
